Introduction
With the latest power supply technology SilverStone Nightjar SST-ST45NF enables the continuous power output at 450W and possesses a high peak rating at 500W. Constructed with server-level components and downgraded from 600W to 450W, SST-ST45NF fan-less thermal solution can easily satisfy the enthusiasts who require stable output and non-noise requirement. Its server-level components ensure the stable and continuous output and 0 dBA acoustics feature enable no noise result while operating, moreover its single PCI-E 8pin and dual PCI-E 6pin can support high-end VGA card with efficiency greater than 80%. SST-ST45NF extruded aluminum construction not only helps the cooling performance but also create an aesthetic innovation which can be seen as a breakthrough of appearance design and can be seen as the best choice for people who require no noise and stable continuous performance.
Special Feature
Fan-less thermal solution, 0 dBA acoustics
450W continuous power output rated with 500W peak
Server-level components
Status indicator LEDs
Single PCI-E 8pin, dual PCI-E 6pin support High-end VGA
Active PFC
Support ATX 12V 2.3 & EPS 12V
Efficiency greater than 80%
Model No. |
SST-ST45NF |
Max. DC Output |
450W at 180Vac~264Vac/ 400W at 110Vac~180Vac |
Load Range -Max DC output : 450W (Peak 500W) at 180Vac ~ 264Vac |
|
+3.3 |
+5V |
+12V |
-12V |
+5VSB |
Max.(Amps) |
22A |
15A |
35A |
0.5A |
2.5A |
Peak (Amps) |
/ |
/ |
40A |
/ |
3.5A |
Min.(Amps) |
0A |
0A |
0.5A |
0.1A |
0A |
Range (%) |
?5% |
?5% |
?5% |
?10% |
?5% |
Line Reg.(%) |
?1% |
?1% |
?1% |
?1% |
?1% |
Ripple(mVp-p) |
50mV |
50mV |
120mV |
120mV |
50mV |
Load Range -Max DC output : 400W (Peak 450W) at 110Vac ~ 180Vac |
|
+3.3V |
+5V |
+12V |
-12V |
+5VSB |
|
20A |
14A |
32A |
0.5A |
2.5A |
|
/ |
/ |
36A |
/ |
3.5A |
|
0A |
0A |
0.5A |
0.1A |
0A |
|
?5% |
?5% |
?5% |
?10% |
?5% |
|
?1% |
?1% |
?1% |
?1% |
?1% |
|
50mV |
50mV |
120mV |
120mV |
50mV | | |
combined +3.3, +5V |
130W |
combined +12V |
420W/35A |
Input Voltage |
100V~264V |
Input Frequency Range |
47Hz ~ 63Hz |
PFC |
Active PFCiPF>0.99 at Full Loadj |
Efficiency |
over 82% |
MTBF |
100,000 hours at 25‹Ciat Full Loadj |
Operating temperature |
30‹C |
Protection |
Over Current Protection Over Power Protection Under Voltage Protection Over Voltage Protection Short Circuit Protection No Load Protection |
Connectors |
1 x 24 / 20-Pin Motherboard connector.i550mmj 1 x 8 / 4-Pin EPS / ATX 12V connector.i550mmj 1 x 6-Pin PCIE connector.i550mmj 1 x 8 / 6-Pin PCIE connector.i550mmj 6 x SATA connector.i500mm / 250mm / 250mmj 6 x 4-Pin Peripheral connector.i500mm / 250mm / 250mmj 2 x 4-Pin Floppy connector.i500mm / 250mm / 250mm / 150mmj |
Color |
Silver |
Cooling System |
Fan Less thermal solution |
Noise Level |
0dBA |
Dimension |
150 mm (W) x 86 mm (H) x 160 mm (D) |
Weight |
2.8 kg. |
Certification |
80 PLUS BRONZE |
