Silverstone SST-CS340 4-Bay U.2 Tri-Mode Hot-Swap High-Performance Mini-ITX NAS Chassis

Price:
 $359.00
MPN:
 SST-CS340
Brand:
UPC:
 844761030254
Availability: Ships in 2 business days
.
Shipping:
 Calculated at checkout


Add to Wishlist

Click the button below to add the Silverstone SST-CS340 4-Bay U.2 Tri-Mode Hot-Swap High-Performance Mini-ITX NAS Chassis to your wish list.

SHARE
Pin It

Product Description

  • Supports 4 x 3.5"/2.5" U.2 NVMe / SATA / SAS Tri-Mode hot-swappable drives
  • Backplane equipped with 2 x SlimSAS 8i (SFF-8654) connectors, supporting PCIe 4.0 with transfer speeds up to 64Gbps
  • Supports Mini-ITX and Deep Mini-ITX motherboards, with graphics card compatibility up to 253mm
  • Supports 2 x 80mm front fans
  • Removable motherboard tray design for easy system installation and maintenance
  • Supports Kensington lock, lockable front door, and chassis intrusion detection switch
  • Lockable power button design
  • Front I/O includes 1 x USB Type-C and 2 x USB 3.0 ports
Model No.
SST-CS340
Motherboard
Mini-ITX,Deep Mini-ITX
Material
Steel, Plastic
HDD backplane
backplane
  • NVMe U.2 (SFF-8639) x 4, supports up to PCIe 4.0 or SAS 12Gb/s / SATA 6Gb/s ［2］
power connector
  • 4-pin peripheral x 1, 15-pin SATA x 1
interface
  • 2 x SlimSAS 8i (SFF-8654), supports up to PCIe 4.0
    or 4 x 7-pin SATA connectors, or SAS primary channel connection ［3］
Drive Support
External
  • 9.5mm slim ODD x 1 , 2.5" / 3.5" SAS / SATA external hot-swap x 4
Internal
  • 2.5” x 1
Cooling system
Front
  • 80mm x 2 (optional)
Rear
  • 120mm x 1 (1 x 120mm fan included)
Internal
  • 60mm x 1 (optional)
    *Rear of drive cage
Limitation of CPU cooler
65mm
Expansion Slot
1
Limitation of expansion card
Length
  • 250mm
Width
  • 113mm
Power Supply
Flex ATX PSU
Limitation of PSU
235mm
Front I/O Port
USB Type-C x 1
USB 3.0 x 2
Front buttons
Power reset
LED Indicators
Power LED x 1: White
HDD Access x 1: White blinking
UID LED x 1: White
Alarm LED: x 1 Red
LAN LED x 2: Green
HDD Tray
  • HDD Power LED: Green
    HDD Access : Blue blinking
Dimension
220mm (W) x 225mm (H) x 300mm (D), 14.85 liters
8.66" (W) x 8.86" (H) x 11.81" (D)

Other Details

MPN:
SST-CS340
