Large Aluminum base enhances great thermal conductivity
Using 9.2 cm fan provides more powerful airflow
Silent Solution
4pin PWM, 4wire
Support AMD Socket 754,939,940 and AM2
Compatibility
Application for AMD
AM2 and AM3 series
Athlon 64 X2 )~4200+
~5600+(AM2
Athlon 64 ~ 4000+
Athlon 64 FX-51/53/55/57
Opteron 140 ~ 154 / 240 ~ 256 / 840 ~ 856
Dual-Core Opteron 265 ~ 285 / 865 ~ 89
Sempron ~ 3800+ (AM2)
Overall Dimension: 92 x 92 x 56 mm
Fan Dimension : 92 x 92 x 25 mm
Heatsink Metarial: Aluminum
Rated Voltage : 12v
Rated Current : 0.24A
Power Consumption : 2.88w
Rated Speed : 2750 ±15% RPM
(Add Heatsink to Fan)
Rated Speed : 2600 ±15% RPM
Airflow : 47.2 CFM
Static Pressure : 0.09 InchH2O
Noise Level: <28.2 dBA
No. of Pole: 4 Pole
Rotation Direction : Clockwise
Bearing Type: Ever Lubricate bearing
(Long Life bearing)
Life Time : 40,000 Hours
(Ambient Temp: 25°C
