P/N | CL-F043-PL14SW-A |
Fan Dimension | 140 x 140 x 25 mm |
Started Voltage | 9.0 V |
Rated Voltage | 12 V |
Rated Current | 0.26 A |
Power Input | 3.12 W |
Fan Speed | 800 ~ 1400 R.P.M 600~1100 R.P.M (Low Noise Mode) |
Max. Air Pressure | 0.515 ~ 1.58 mm-H2O |
Max. Air Flow | 29.229~ 51.15 CFM |
Noise | 19 ~ 28.1 dB-A |
Bearing Type | Hydraulic Bearing |
Life Expectation | 40,000 hrs,25℃ |
Connector | 4P PWM (Controller To M/B) 2510-5P ( Fan To Controller ) |
Weight | 191.6 g |
LED Light | Red -> Blue -> White -> Green -> LED off -> 256 colors |
