P/N | CA-1Y4-00SEWN-00 |
---|---|
SERIES | The Tower |
CASE TYPE | Micro Tower |
DIMENSIONS | 551 x 342 x 281 mm (22.5 x 14 x 11.5 inch) |
WEIGHT | 8.3 kg / 18.3 lbs. |
SIDE PANEL | 3mm Tempered Glass x 3 |
COLOR | Racing Green |
MATERIAL | SPCC |
COOLING SYSTEM | Top(exhaust): 140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 2 |
EXPANSION SLOTS | 4 |
MOTHERBOARD | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX) |
I/O PORT | USB 3.2 (Gen 2) Type-C x 1 |
PSU | Standard PS2 PSU (optional) |
FAN SUPPORT | Top: 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Right Side: 3 x 120mm, 2 x 120mm, 1 x 120mm 3 x 140mm, 2 x 140mm, 1 x 140mm Rear: 2 x 120mm, 1 x 120mm 2 x 140mm, 1 x 140mm Power Cover: 1 x 120mm 1 x 140mm |
RADIATOR SUPPORT | Right Side(AIO): 1 x 360mm, 1 x 240mm, 1 x 120mm 1 x 420mm, 1 x 280mm, 1 x 140mm |
CLEARANCE | CPU cooler height limitation: 210mm VGA length limitation: 280mm(With power cover) 400mm(Without power cover) PSU length limitation: 220mm |
