Sorry but this item is currently unavailable.
Please check back at a later stage.
Model | Core X5 |
P/N | CA-1E8-00M1WN-00 |
Case Type | E-ATX Cube Case |
Dimension (H x W x D) | 463 x 371 x 540 mm (18.2 x 14.6 x 21.3 inch) |
Net Weight | 12 kg / 26.5 lb |
Side Panel | Transparent Window |
Color | Exterior & Interior : Black |
Material | SGCC |
Cooling System | Front (intake) : 120 x 120 x 25 mm Turbo fan (1000rpm, 16dBA) Rear (exhaust) : 120 x 120 x 25 mm Turbo fan (1000rpm, 16dBA) |
Drive Bays | 3 x 5.25’’ -Accessible:4 x 3.5’’ or 2.5’’ (HDD Cage) -Hidden:3 x 2.5’’ (HDD Tray) |
Expansion Slots | 8 |
Motherboards | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13” (Extend ATX) |
PSU | Standard PS2 PSU (optional) |
I/O Port | USB 3.0 x 2, USB 2.0 x 2,HD Audio x 1 |
LCS Upgradable | Supports 1/2”、3/8”、1/4” water tube |
Fan Support | Front: 3 x 120mm , 2 x 140mm , 1 x 200mm Top: 6 x 120mm , 4 x 140mm , 2 x 200mm Rear: 1 x 120mm , 1 x 140mm Bottom: 6 x 120mm Left / Right Side: 3 x 120mm |
Radiator Support | Front: 1 x 360mm , 1 x 280mm , 1 x 200mm Top: 2 x 360mm , 1 x 280mm , 1 x 400mm Rear: 1 x 120mm , 1 x 140mm Bottom: 2 x 360mm Left / Right Side: 1 x 360mm |
Clearance | CPU cooler height limitation: 230mm VGA length limitation: 330mm(with ODD Cage) 480mm(without ODD Cage) PSU length limitation: 220mm (With Bottom Fan) |
