What's New !
What has NOT changed
Radiator body | |
Material | Brass tubes, louvered copper fins |
Body dimensions | 140 mm x 293 mm x 28 mm |
Fill-port thread class | G 1/4 |
Barb fittings | Integrated swivel 90° elbows, 3/8" (10mm) OD |
Installation hardware |
|
Lighting type | ALED |
Reservoir | |
Material | Acrylic |
Capacity | 109 ml |
Lighting type | ALED |
Pump | |
Pump speed control | PWM |
Pump Speed range | 1200 ~ 3000 RPM |
Pump nominal voltage | 12 VDC |
Pump nominal power | 6W |
Max. Static Pressure | 2.8 mH₂O |
Max. discharge | 11 l/mn |
Redundant fail safe |
|
Pump Bearing type | Ceramic shaft, PTFE bearing |
Pump Power connector | SATA |
Pump RPM & PWM connector | Mini 4-pin |
Pump MTBF | 60,000 hours |
ROHS | Compliant |
Pre-installed Helix™ Fan (2 each) | |
Dimensions | 140 mm x 140 mm x 25 mm |
Speed control | PWM |
Speed range | PWM adjustable 700 ~ 1800 RPM |
Airflow range | 35 ~ 90 CFM |
Static pressure range | 0.25 ~ 2.29 mmH₂O |
Noise level range | <8.3 ~ <28.8 dB/A |
Nominal Voltage | 12 v |
Power input | 2.4 W |
Bearing Type | Z-axis |
Connector | Mini 4-pin |
MTBF | 60,000 hours |
ROHS | Compliant |
Apogee™ XL2 Waterblock (1 each) | |
Housing material | Clear acrylic |
Base plate material | C110 copper |
Cooling engine | 0.25mm x 0.25mm micro-pin array |
Barb fittings | Swivel elbows, 3/8" (10mm) OD |
Port thread | G1/4 standard |
Installation hardware & processor + socket compatibility |
|
Lighting type | ALED |
Tubing & Coolant | |
Material | PVC tubing |
Color | Clear |
Dimensions | 5/8" x 3/8" (16/10mm) |
Coolant | Pre-filled with non-toxic propylene glycol coolant mix |
Clamps (4 each) | |
Material | Black anodized aluminum |
PWM splitter (1 each) | |
PWM Ports | 4 |
RPM signal port | Channel 1 |
ALED connectors | 3 |
2 pin connector | 1 |
Power connector | SATA |
PWM/RPM connector | Mini 4-pin |
Installation hardware | Peel-off sticker, mounting screws & nuts |
ROHS | Compliant |
Tim-Mate 2, 1g syringe thermal compound | |
Quick Installation Guide |
