■ Four Ø6mm heat-pipe with aluminum fins for excellent heat conducting efficiency
■ High reliability with dual ball bearing, PWM controlled fan
■ Compatible with Intel LGA 2011 / 2066 Square & Narrow sockets
Model No. | SST-XE02-2066 |
Application | Intel LGA 2011 / 2066 Square & Narrow |
Material | Copper heat pipes with aluminum fins |
Fan dimension | 60mm (W) x 25mm (H) x 60mm (D) 2.36" (W) x 0.98" (H) x 2.36" (D) |
Fan speed | 1600~8400RPM |
Air Flow (CFM) | 43 CFM |
Air pressure | 21.08 mmH2O |
Noise | 52dBA |
Rated Voltage | 12V |
Rated Current | 0.38A |
Bearing | Dual ball bearing |
Life Expectance (hrs) | 140,000 hours |
Connectors | 4 pin PWM |
CPU TDP | 165W |
Net weight | 405g |
Dimension | 90mm (W) x 64.5mm (H) x 90mm (D) 3.54" (W) x 2.54" (H) x 3.54" (D) |
