73mm (W) x 65mm (H) x 87mm (D) 2.87" (W) x 2.56" (H) x 3.43" (D)
Material
Copper base with plastic body
Pump
Motor speed
3,000 ±10% RPM
Rated Voltage
12V
Rated Current
0.38A
Connectors
2510 - 3 pin
Radiator
Dimension
120mm (W) x 28mm (H) x 396mm (D) 4.72" (W) x 1.1" (H) x 15.59" (D)
Material
Aluminum
Tube
Length
460mm
Material
Rubber
Fan
Dimension
120mm (W) x 25mm (H) x 120mm (D) 4.72" (W) x 0.98" (H) x 4.72" (D)
Speed
500 ~ 2200 RPM
Noise level
11.3~35.5 dBA
Rated Voltage
12V
Max airflow
83.68 CFM
Max air pressure
4.01 mm/H2O
Connector
4 pin PWM & 4-1 pin ARGB (5V LED)
Remark
* Please ensure that the control box and the RGB port on the motherboard you wish to connect are compatible with the RGB port definition of the IceMyst series. An incorrect connection may result in malfunctions or damage.
