Material
|
Aluminum door and top panel, steel body | |
|
Motherboard
|
SSI-EEB, SSI-CEB, Extended ATX, ATX, Micro-ATX | |
|
Multimedia
|
-- | |
|
Drive Bay
|
External | 5.25" x 2 |
| -- | ||
| Internal
|
3.5" x 7 (2 hot-swap) , 2.5” x 4 | |
|
Cooling System
|
Front | 2 x AP182 180mm intake fan 500~2000rpm, 17~42 dBA(compatible with 3 x 120mm fan) |
| Rear | 1 x 120mm fan slot | |
| Side | -- | |
| Top | -- | |
| Bottom | -- | |
| Internal | -- | |
|
Expansion Slot
|
8 | |
|
Front I/O Port
|
USB 3.0 x 2 audio x 1 MIC x 1 |
|
|
Power Supply
|
1 x Optional standard PS2(ATX) no length limitation | |
|
Operating system support
|
-- | |
|
Expansion Card
|
Compatible up to 13.3” long, width restriction-6.69" | |
|
Limitation of CPU cooler
|
165mm | |
|
Limitation of PSU
|
-- | |
|
Net Weight
|
11.5kg | |
|
Dimension
|
219mm (W) x 546mm (H) x 482mm (D), 57.6 liters | |
|
Extra
|
Support Kensington locks One CP05 included for single hot-swappable SATA hard drive, additional CP05 can be purchased separately | |
