■ Steel honeycomb mesh design providing superior intake volume to cool internal components
■ Precisely designed interior provides sufficient space for high end graphics card and multiple cooling options
■ Adjustable drive cage allows flexibility in PSU size and cable management space
■ I/O ports includes USB 3.0 x 1, USB 2.0 x 2, Audio x 1 and MIC x 1
■ Removable filters on top and bottom make cleaning out dust a breeze
Motherboard | Micro-ATX, Mini-DTX, Mini-ITX | |
Drive bay | External | -- |
Internal | 3.5" x 2 (compatible with 2.5" x 1) 2.5" x 2 |
|
Cooling system | Front | 120mm x 2 / 140mm x 2 |
Rear | 120mm x 1 (120mm fan x 1 included) | |
Side | -- | |
Top | 120mm x 2 | |
Bottom | -- | |
Internal | 120mm x 2 | |
Radiator support | Front | 120mm / 240mm |
Rear | 120mm | |
Top | -- | |
Bottom | -- | |
Internal | -- | |
Expansion slot | 4 | |
Front I/O port | USB 3.0 x 1 USB 2.0 x 2 Audio x 1 MIC x 1 |
|
Power supply | Standard PS2(ATX) | |
Limitation of expansion card | Length : 320mm without front fan installed Width : 160mm |
|
Limitation of CPU cooler | 160mm | |
Limitation of PSU | 160mm with 3.5" cage installed 250mm without 3.5" cage installed |
|
Dimension | 210mm (W) x 392mm (H) x 366mm (D), 30.13 liters 8.27" (W) x 15.43" (H) x 14.41" (D), 30.13 liters |
