■ Integrated display for monitoring voltage and current
■ Supports current up to 2A for each USB port
■ Provides four 5Gbps Super Speed USB 3.0 USB ports
■ High quality brushed aluminum design
■ Supports over voltage and over current protection
■ Includes AC adapter for stable power delivery
■ Compliant with USB power delivery specification 1.2
Model No. | SST-EP03B |
Material | Aluminum & plastic |
Chipset | GL3522 |
Power requirement | Input : AC 100V~240V 50~60Hz, Output : DC 5V / 3.5A |
Interface | USB 3.0 (Compatible with USB 2.0 / 1.1) |
Data Transfer Rate | USB 3.0 up to 5 Gbps |
Charging Spec | USB battery charging 1.2 compliant |
Detect range | Voltage : 0-5.5V Error ± 0.1V Current : 0-2.5A Error ± 0.1A |
Temperature | Operating : 0℃~65℃ Storage : 0℃~65℃ |
Humidity | Operating : 10%~90% Storage : 5%~95% |
Net Weight | 358g ± 20g |
Operating system support | Microsoft Windows 10/8.1/8/7/Vista/XP(32-bits/64-bits) or future release versions. Mac OS X, Linux |
Dimension | 51 mm (W) x 31.5mm (H) x130 mm (D) |
