■ Bi-directional mounting bracket design
■ 3 x Ø6mm heat-pipes and aluminum fins for excellent heat conducting efficiency
■ 60mm dual ball bearing PWM fan
■ Compatible with AMD AM4 socket
Model No. | SST-AR09-AM4 |
Application | AMD Socket AM4 |
Material | Copper heat pipes with aluminum fins |
Fan dimension | 60mm (W) x 25mm (H) x 60mm (D) 2.36" (W) x 0.98" (H) x 2.36" (D) |
Speed (R.P.M.) | 1200 ~ 5000 RPM |
Air Flow (CFM) | 27.9 CFM |
Air pressure | 4.83mmH2O |
Noise | 18.02~42.5 dBA |
Rated Voltage | 12V |
Rated Current | 0.35A |
Bearing | Dual ball bearing |
Fan MTTF | 70,000 hours |
Connectors | 4 Pin PWM |
Net weight | 295g |
Dimension | 71mm (W) x 66mm (H) x 102mm (D) 2.8" (W) x 2.6" (H) x 4.02" (D) |
