■ Industry leading air channeling fan
■ Dual ball bearing for longer lifetime use
■ Mixed fan blade design for noise reduction
■ Integrated air channeling grille double as fan guard to reduce overall size
■ Low power consumption
■ Wide 0-2000 RPM speed range via PWM control allowing performance on demand
Material | PBT |
Color | Black |
Bearing | Dual ball bearing |
Connectors | 4pin PWM |
Rated Voltage | 12V DC |
Start Voltage | 7V |
Rated Current | 0.21A |
Rated Power | 2.52W |
Speed | 0-2000rpm |
Airflow | 0~74 CFM |
Static Pressure | 0~2.52mm-H2O |
Noise Level | 0~38.9dBA |
Life Time | 70,000 hours |
Dimension | 120mm (L) x 120mm (W) x 25mm (H) 4.72" (L) x 4.72" (W) x 0.98" (H) |
