Silverstone FX121 SFF Cross Flow Fan

Price:
 $24.70
MPN:
 FX121
Brand:
Condition:
 NEW
Availability: Ships in 2 business days
Ships in 2 business days
Shipping:
 Calculated at checkout


Sorry but this item is currently unavailable.

Please check back at a later stage.

Add to Wishlist

Click the button below to add the Silverstone FX121 SFF Cross Flow Fan to your wish list.

SHARE
Pin It

Product Description

Introduction
  The FX121 is a cross flow fan developed in conjunction with Sugo series chassis. When installed, it facilitates the dissipation of heated air developed around the CPU voltage regulators and other motherboard components.

  Special Feature
  Vibration damping mounts
Effective thermal solution
Compact size suitable for SFF applications
Compatible with SilverStone Sugo Series
Great for use in SilverStone SG01

DIMENSION  130 x 45 x 40.6mm (overall)
108 x 32mm (mounting holes)
 ITEMS  STANDARD  REMARKS
 Material
  Aluminum blades, SECC frame

 BEARING
  Two ball & one sleeve

 RATE VOLTAGE
  12V DC

 START VOLTAGE
  8V DC

 RATED CURRENT
  0.12 Amp
  IN FREE AIR AT RATED VOLTAGE
 SPEED
  3000 rpm +_ 10% rpm
  IN FREE AIR AT RATED VOLTAGE
 AIRFLOW
  14 CFM
0.38m3 / MIN
  AT RATED VOLTAGE
 AT ZERO STATIC PRESSURE
 STATIC PRESSURE
  0.90mmH2O
  AT RATED VOLTAGE AT ZERO AIRFLOW
 NOISE LEVEL
  26 dB(A)
  IN FREE AIR AT RATED VOLTAGE
 CUNSUMING POWER
  1.44W
  IN FREE AIR AT RATED VOLTAGE
 LIFE TIME
  15,000 hours

 OPERATING TEMPERATURE
  0°C~ 45°C




Other Details

MPN:
FX121
