The Kama Bay Amp Mini Pro is based on the Kama Bay Amp Mini - but it has learned from its' "stablemate", and comes along with some improvements here and there. Beating at its' heart is the new, but proven MAXIM Max98400A IC - boosting the analog input signal by employing pulse with modulation, ensuring a faithful sound reproduction. Functions include a mute-setting as well as the possibility to convey the USB-port of the PC to the amp's front USB connector.
Maxim MAX98400A Power IC-Chip
The featured Maxim MAX98400A digitally boosts the analog input signal by applying pulse width modulation. The chip enables a faithful sound reproduction while maintaining economical energy consumption.
Gold-Plated Connectors
The Kama Bay Amp Mini Pro is fitted with high-grade, gold-plated connectors which minimize loss of transferred data at the connected points, and convey a high-end feel to the product.
Universal Application
The Kama Bay Amp Mini Pro fits neatly into a 3.5" (8.89 cm) bay of a PC case, but can as well find a home outside as a stand-alone, for PC-independent usage. The front USB-connector offers a convenient way for charging MP3-players as well as smartphones.
» Model Name
Kama Bay AMP Mini Pro
» Model Number
SDA35-2000-BK
» Output
2 x Speaker , 1 x Headphones
» Input
1x 3.5mm Stereo Mini , 1x RCA jack
» Power IC
MAXIM MAX98400A
» Channel
2 Stereo channels
» Continous Max. Output
20 W x 2 Channels (1KHz / 8 Ω)
» SN Ratio
75 dB
» Harmonic Distortion Rate
0.5% (1 KHz / 1 W)
» Input Voltage
12V ~ 24V (DC)
» Power supply via AC adapter
19.5V / 3A
» Dimensions
105.5 x 33.5 x 153 mm / 4.15 x 1.32 x 6.02 in (W x H x D) *** With fitted side panels & insulator feet ***
» Weight
343 g / 12.12 oz
» Included Parts
AC adaptor, speaker cable, manual, audio cable (stereo mini - RCA jack / RCA jack - RCA jack / stereo mini - stereo mini ), mounting screws, 2 PCI-bracket, PCI bracket screw, USB-relay cable (5-pin ⇔ 4-pin), USB-relay cable, spare USB connector cap
