CAP
Material:Aluminum and plastic
Display Orientation:Software adjustable Default, +90, +180, and -90 Degrees
Display Panel Active Area:1.54" (39.1mm)
Display Resolution:240 x 240 px
Display Brightness:300 cd/m²
Display Panel Type:Transmissive TFT, 262K color
WATER BLOCK
Dimensions:Diameter: 74.7mm H: 55.97mm
Material:Block: Copper Housing: Plastic
PUMP
Motor Speed:800 - 2,800 ± 300RPM
Power:12V DC, 0.3A
RADIATOR
Dimensions:121 x 394 x 27mm
Material:Aluminum
TUBE
Length:400mm
Material:Ultra-low Evaporation Rubber with Nylon Braided Sleeve
FAN SPECS
Model:F120P Static Pressure Fan
Quantity:3
Dimension:120 x 120 x 26mm
Speed:500-1,800 ± 180 RPM
Air Flow:21.67 - 78.02 CFM
Air Pressure:0.75 - 2.7mm-H2O
Noise:17.9 - 30.6dBA
Bearing:Fluid Dynamic Bearing
Power Consumption:12V DC, 0.23A, 2.76W
Connector:4-pin PWM
Life:60,000 hours / 6 Years
COMPATIBLE SOCKET & CPU
Intel:Intel Socket LGA 1700 & 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron
AMD:AMD Socket AM5, AM4, sTRX4*, TR4* (*Threadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper
