* Heavy duty full metal construction with suggested applications in Imaging, Medical,
and Military systems, Media servers, and IPCs.
* Supports up to 4 x 2.5" SATA/SAS HDD/SSD into a single 5.25" bay
* Support SATA 6Gbps or SAS single channel
* Accommodates 2.5" drives with 7mm, 9mm, 12.5mm & 15mm Height
* Active Power Technology (APT) - only powers up if there is drive installed in the drive bay
* Eagle-hook lock system & custom made steel key lock keeps drives secure within the enclosure
* Full Metal EZ Slide Mini Tray System with built-in drive protection cover and lock
* Removable EZ Slide Mini Tray system for easy maintenance
* Perfect for rugged applications and complies to flammability requirements
* Indicator LED provided for each bay
* Dual 40mm Cooling Fans
|
Model Number :
|
MB994SK-1B
|
|
|
|
|
Host Interface :
|
4 x 7pin SATA
|
|
|
Drive Fit :
|
4 x 2.5" SAS or SATA I/ II/ III HDD/ SSD
|
|
|
Drive Bay :
|
Single 5.25" half height device bay
|
|
|
Transfer Rate :
|
Up to 6 Gb/sec. (depending on hard drive speed)
|
|
|
Power Input :
|
2 x 4pin Molex power port
|
|
|
Insert& Extract connection Via :
|
Direct SAS/ SATA hard drive connection
|
|
|
Structure :
|
Aluminum & SECC
|
|
|
Drive Cooling :
|
40mm rear cooling fan x 2 & metal heat dispersion
|
|
|
LED Indication :
|
Device Power & Drive Activity
|
|
|
LED Color :
|
Green : Device Power ; Amber : Drive Activity
|
|
|
Drive Security :
|
Custom Steel Lock
|
|
|
Dimension (L x W x H) :
|
6.70" x 5.75" x 1.63"
|
|
|
|
