Icy Dock MB492SKL-B ToughArmor Rugged Full Metal Dual 2.5in SAS/SATA HDD/SSD Mobile Rack

Price:
 $109.99
MPN:
 MB492SKL-B
Brand:
UPC:
 884826002444
Condition:
 NEW
Shipping:
 Calculated at checkout


Add to Wishlist

Click the button below to add the Icy Dock MB492SKL-B ToughArmor Rugged Full Metal Dual 2.5in SAS/SATA HDD/SSD Mobile Rack to your wish list.

SHARE
Pin It

Product Description

  • Features:Support Drive Size: 2.5" SATA HDD/SSD
    • Low profile design for small form factor applications such as industrial small PCs, surveillance, embedded systems, automation systems, aerospace systems and mobile DVR systems
    • Fits two drives in a single 3.5" front device bay which is perfect for RAID configurations
    • Dual Lock Design - Metal key lock (for drive security) and thumb screw lock (for impact/vibration)
    • Removable drive tray design allows easy maintenance and fully supports SATA hot-swap
    • Unique drive ID plugs for drive trays are included (#1 - #8)
    • Fits 2x 5mm to 9.5mm height 2.5" SATA HDD or SSD in a external 3.5" drive bay
    • Supports SAS or SATA HDD/SSD at 6Gbps and is backwards compatible with SATA 3Gbps drives and hosts (SAS host is required for SAS drives)
    • Rugged Heavy Duty Full Metal construction, perfect for enterprise applications
    • Multi-Flow Technology - provides excellent passive cooling
    • Anti-Vibration Technology - creates a safe environment for hard drives or SSDs
    • Active Power Technology (APT) - individual led only powers up if there is drive installed in the drive bay
    • EMI Grounding - protects hard drives from electrical damage
    • Locking latch for both SATA 7 pin data port and SATA 15 pin power port
  • Compatible Drive Type: SATA / SAS (Support Single Channel SAS)
  • Number of Drives: 2
  • Max Drive Height: 9.5mm
  • Drive Bay: 1x 3.5" device bay
  • Host Interface: 2x 7pin SATA
  • Power Input: 1x SATA 15 pin power
  • Transfer Rate: Up to 6Gb/sec per SATA channel(Depending on drive speed)
  • Support HDD Capacity: No Limitation
  • Drive Cooling: Metal heat dispersion
  • RAID Function: N/A
  • Structure / Material: Full Metal
  • Support Hot-Swap: Yes
  • Drive Security: Thumb screw lock & 2-segment keylock
  • RAID Status LED Indicator: N/A
  • Drive Activity LED Indication: Drive power - solid green; HDD access - flashing green
  • SATA Connector Insertion Rate: 10,000
  • Compliance: CE, RoHS, REACH
  • Color: Black
  • Dimensions (WxLxH): 101.2 x 138.0 x 25.4 mm
