CPU Socket | C32/F 1207 |
CPU Support | AMD® Socket C32 Opetron 4100 Series 4184, 4180, 4130 , 4122, 4176HE, 4174HE, 4170HE, 4164EE, 4162EE & Shanghai & Barcelona processors -Third-Generation Opteron 2300 & 8300 series |
Solution | 2U&Up |
Overall Dimension | 100.0 x 71.0 x 65.50 mm |
Weight | 275 g |
Material | Aluminum Heatsink |
Fan Dimension | 60 x 60 x 25 mm |
Speed | At Duty Cycle 20%: 1100 RPM At Duty Cycle 50%: 2500 RPM At Duty Cycle 100%: 6000 RPM |
Bearing | 2 Ball Bearing |
Rated Voltage | 12 V |
Power | At Duty Cycle 20%: 0.60 W At Duty Cycle 50%: 1.44 W At Duty Cycle 100%: 3.60 W |
Air Flow | At Duty Cycle 20%: 6.0 CFM At Duty Cycle 50%: 28.1 CFM At Duty Cycle 100%: 32.81 CFM |
Noise Level | At Duty Cycle 20%: 16.0 dBA At Duty Cycle 50%: 28.1 dBA At Duty Cycle 100%: 44.7 dBA |
Air Pressure | - |
Lead Wire Pin Out | Pin1-Black (-) Pin2-Yellow (+) Pin3-Green (Techometer/Signal output) Pin4-Blue (PWM) |
Note | 1. Tyan Socket F 1207 motherboards for 3.5" mounting pitch : S2915, S2927, S2932, S3970G2NR, S3970G2N-U, S3992 and S4985 + M4985 2. 3.5" Mounting Pitch 3. Backplate is not included 4. RoHS Compliance |
