Sorry but this item is currently unavailable.
Please check back at a later stage.
CPU Socket | Intel Socket: LGA 2011 / 1366 / 1156 / 1155 / 775 * AMD Socket: FM1 / AM3+ / AM3 / AM2+ / AM2 |
CPU Support | Intel: Core™ i7 Extreme / Core™ i7 / Core™ i5 / Core™ i3 / Core™2 Extreme / Core™2 Quad / Core™2 Duo / Pentium / Celeron AMD: FX-Series / A-Series / Phenom™ II X4 / Phenom™ II X3 / Phenom™ II X2 / Phenom™ X4 / Phenom™ X3 / Athlon™ II X4 / Athlon™ II X3 / Athlon™ II X2 / Athlon™ X2 / Athlon™ / Sempron™ |
Dimension | 120 x 80 x 159 mm (4.7 x 3.1 x 6.3 in) |
Heat Sink Dimensions | 116 x 51 x 159 mm (4.6 x 2.0 x 6.3 in) |
Heat Sink Material | 4 Direct Contact Heat Pipes / Aluminum Fins |
Heat Sink Weight | 465g (1.03 lb) |
Heat Pipes Dimensions | ø6mm |
Fan Dimension | 120 x 120 x 25 mm (4.7 x 4.7 x 1 in) |
Fan Speed | 600 – 2,000 RPM (PWM) ± 10% 600 – 1,600 RPM (PWM) ± 10% (EU Version) |
Fan Airflow | 24.9 – 82.9 CFM ± 10% 24.9 – 66.3 CFM ± 10% (EU Version) |
Fan Air Pressure | 0.3 – 2.7mm H2O ± 10% 0.3 – 1.7mm H2O ± 10% (EU Version) |
Fan Life Expectancy | 40,000hrs |
Fan Noise Level (dB-A) | 9 - 36 dBA 9 - 31 dBA (EU Version) |
Bearing Type | Long Life Sleeve Bearing |
Connector | 4-Pin |
Fan Rated Voltage | 12 VDC |
Fan Rated Current | 0.22A |
Power Consumption | 2.64W |
Fan Weight | 104g (0.23 lb) |
