CPU Socket | Intel LGA 2011 / 1366 / 1156 / 1155 / 775 AMD Socket FM1 / AM3+ / AM3 / AM2 |
Dimension | ø 70 x 27mm (ø 2.75 x 1.1 inch) |
Radiator Dimensions | 150.3 x 118 x 27mm (5.9 x 4.6 x 1.1 inch) |
Radiator Material | Aluminum |
Fan Dimension | 120 x 120 x 25 mm (4.7 x 4.7 x 1 in) |
Fan Speed | 600~2400 RPM (PWM) ± 10% |
Fan Airflow | 19.17 ~ 86.15 CFM ± 10% |
Fan Air Pressure | 0.31 ~ 4.16 mm H2O ± 10% |
Fan Life Expectancy | 40,000 hours |
Fan Noise Level (dB-A) | 19 ~ 40 dBA |
Bearing Type | Rifle bearing |
Connector | 4-Pin |
Fan Rated Voltage | 12 VDC |
Fan Rated Current | 0.3A |
Power Consumption | 3.6W |
Pump Life Expectancy | 70,000 hrs |
Pump Noise | 17dBA |
Pump Rated Voltage | 12 VDC |
Pump Power | 1.8W |
