The product is equipped with Zalman’s patented VFP (Variable Fin Profile) technology. Fan installed inside the heatsink maximizes the cooling efficiency and the product’s maximized dissipation surface area provides excellent performance.
Use of four high performance heatpipes maximizes heat transfer.
Pure copper thin fins (0.3mm) for excellent cooling performance.
Cools not only the VGA chipset and VGA RAM, but all other VGA components as well.
80mm Slim LED Fan for excellent performance and great aesthetics.
Newly improved installation structure provides easy installation and broad compatibility.
Adjustable fan speed controller(FAN MATE 2) enables control of noise and fan speed.
Does not generate noise or vibration in Silent Mode.
Dimensions
160(L) x 80(W) x 30(H) mm
Weight
380g
Base Material
Dissipation Fins : Pure Copper Base : Pure Copper, Heatpipe : Pure Copper
Dimensions
80(L) x 80(W) x 15(H) mm
Bearing Type
2 Ball-Bearing
Speed
Silent Mode
1,400rpm ± 10 %
Normal Mode
2,500rpm ± 10 %
Noise Level
Silent Mode
18.0dBA ± 10 %
Normal Mode
28.0dBA ± 10 %
Nipple Installation Holes
VGA Card
ATI Radeon X1600 Series ATI Radeon X1300 Series ATI Radeon 9*** Series (except 9550/9600) ATI Radeon X*** Series NVIDIA Geforce 6600 Series (except 6600 AGP Series) NVIDIA GeforceFX 5600(FX 5700) NVIDIA GeforceFX 5500 NVIDIA GeforceFX 5200 NVIDIA Geforce4 MX Series
NVIDIA Geforce 6600 Series (except 6600 AGP Series) NVIDIA GeforceFX 5800 Series NVIDIA GeforceFX 5700(Ultra) Series NVIDIA Geforce4 TI 4 Series
ATI Radeon HD4670 ATI Radeon HD4650 ATI Radeon X2600 Series ATI Radeon X1650 Series ATI Radeon X1600 Series NVIDIA Geforce 8600 Series NVIDIA Geforce 8500 Series NVIDIA Geforce 7600 Series NVIDIA Geforce 7300 Series NVIDIA Geforce 6600 Series (except 6600 AGP Series)
NVIDIA Geforce FX 5950 Series NVIDIA Geforce FX 5900 Series
ATI Radeon HD 4870 ATI Radeon HD 4850 ATI Radeon HD 4830 ATI Radeon HD 3870, HD 3850 ATI Radeon X1950 Series ATI Radeon X1900 Series ATI Radeon X1800 Series NVIDIA Geforce GTS250 NVIDIA Geforce 9800GTX+ NVIDIA Geforce 9800GT NVIDIA Geforce 9500GT NVIDIA Geforce 9400GT NVIDIA Geforce 8800GT, 8800GTS (G92) NVIDIA Geforce 7950 Series NVIDIA Geforce 7900 Series NVIDIA Geforce 7800 Series NVIDIA Geforce 7600 Series NVIDIA Geforce 6800 Series
NVIDIA Geforce 8800 Series (G80)
- One (1) VGA Cooler - Eight (8) RAM Heatsinks - Four (4) Nipples - Four (4) Fixing Nuts - Four (4) Fixing Nuts for SLI/CrossFire - One (1) PVC Washer Plate - Eight (8) Rubber Rings - Four (4) Springs - One (1) Thermal Grease - One (1) Fan Controller (FAN MATE 2) - One (1) Cable for FAN MATE 2 - One (1) Double-Sided Tape (to attach FAN MATE 2) - One (1) User’s Manual
